240x128 Graphic LCD Displays CH240128H3
Product Description
1.1 C0B process, double-row pin interface, product with PCB board, backlight, conductive tape connection, stable structure.
1.2 IC uses t6963c/uc6963, chip built-in character library ROM (CGROM), no Chinese character library, programmers compile Chinese character library.
1.3 Low power consumption, 5V/3.3V two power modes, no backlight current within 20mA, backlight current within 180mA.
1.4 LED can be driven by PIN2, PIN3, PIN20.
1.5 Product features:
Built-in display data RAM is 128x240 bits.
Built-in character library ROM (CGROM): 128 characters
Graphic mode, text mode, graphic text mixed mode.
One screen displays 15 characters x 8 lines (16x16 dot matrix).
Single image ≦240x128 dot matrix
Built-in negative voltage output (VEE), V0 and VEE are disconnected when the module contrast is fixed.
8-bit parallel port interface, 8080 timing.
1.2 IC uses t6963c/uc6963, chip built-in character library ROM (CGROM), no Chinese character library, programmers compile Chinese character library.
1.3 Low power consumption, 5V/3.3V two power modes, no backlight current within 20mA, backlight current within 180mA.
1.4 LED can be driven by PIN2, PIN3, PIN20.
1.5 Product features:
Built-in display data RAM is 128x240 bits.
Built-in character library ROM (CGROM): 128 characters
Graphic mode, text mode, graphic text mixed mode.
One screen displays 15 characters x 8 lines (16x16 dot matrix).
Single image ≦240x128 dot matrix
Built-in negative voltage output (VEE), V0 and VEE are disconnected when the module contrast is fixed.
8-bit parallel port interface, 8080 timing.
